4,8mm staal op staal schroef, verzinkt

tap image to zoom

Omschrijving

4,8mm staal op staal schroef, verzinkt

Meer lezen Minder lezen

Norm

Harmonized standard EN 14566:2008+A1:2009

Informatie aanvragen

Specificaties

Article number: 48IP19MC
GTIN: 8715274028149

Technische specificaties

Collation type: Plastic collated
Wire material: Carbon steel standard tensile
Rotations per minute: 2300, 2500, 3000, 3300 RPM

Finish: Clear zinc
Application environment: Indoor
Point type: Type 17 cut point
Pointangle: 110 °
Screw head type: Flat
Screw recess: Philips 2
Screw thread type: Tek
Amount fasteners on strip/coil: 50 - 50
Screw length: 19.0 mm
Screw diameter: 4.8 mm

DOP No: 48IP19MC
Service class: 1
Inner threaded diameter: 3.8 mm
Threaded/profiled length: 13.9 mm
Harmonized standard: EN 14566:2008+A1:2009

Niet-technische specificaties

Package quantity: 1000

Net weight: 2.4 kg
